Item

Specification

3GPP

3GPP protocol

Release 16

5G-4G interworking

NSA option 3/3x，SA option 2

5G

Frequency Band

FDD：N1/3/5/7/8/20/28

TDD：N38/40/41/77/78/79

SUL：N80/81/82/83/84

SDL：N75

Bandwidth

TDD: 100/90/80/70/60/50/40/20/15/10MHz

FDD: 40/30/20/15/10/5MHz

Note: Different frequency bands support different bandwidths

DL MIMO

4*4 MIMO DL: N1/3/7/38/40/41/77/78/79

2*2 MIMO DL: N5/8/20/28/75

UL MIMO

2*2: N1/38/40/41/77/78/79

DL/UL modulation

256QAM/256QAM

DL/UL Peak throughput

5G NR 5.4Gbps/500Mbps (@ DL300MHz/UL 200MHz,SA TDD 8:2 ratio)

No. of Carriers

DL 3CC，300MHz

UL 2CC, 200MHz

4G

Frequency Band

B1/3/5/7/8/18/19/20/26/28/32/34/38/39/40/41/42/43

MIMO

4*4: B1/3/7/38/39/40/41/42/43

2*2: B5/8/18/19/20/26/28/32/34

DL/UL modulation

256QAM/64QAM

Antenna

Antenna Gain

11dBi

Wi-Fi

Protocol

802.11 n 1*1 MIMO 2.4GHz, used for management purpose only

Feature

Smart Phone APP

Basic Feature

Size

230x142x58(mm)

Weight

<1kg

Interface

1 RJ45*2.5GE, Power*1, SIM*1(4FF)

LED

4G/5G

Button

Reset

Working temperature

-40℃ ～ +55℃, without solar radiation

Waterproof

IP65
